PPC-3100S Fanless Panel PC

PPC-3100S Fanless Panel PC

80000 INR/Piece

Product Details:

  • Screen Resolution 391.4 x 312.5 x 55.35 mm (15.41 x 12.3 x 2.18 in)
  • Processor Type Intel
  • CPU Intel
  • Memory 4 Gigabyte (GB)
  • ODD YES
  • HDD 256 Gigabyte (GB)
  • OS WINDOWS / Linux
  • Click to View more
X

PPC-3100S Fanless Panel PC Price And Quantity

  • 80000 INR/Piece
  • 1 Piece

PPC-3100S Fanless Panel PC Product Specifications

  • 4 Gigabyte (GB)
  • 391.4 x 312.5 x 55.35 mm (15.41 x 12.3 x 2.18 in)
  • Intel
  • Intel
  • YES
  • 256 Gigabyte (GB)
  • YES
  • WINDOWS / Linux

PPC-3100S Fanless Panel PC Trade Information

  • Cash in Advance (CID)
  • 50 Piece Per Month
  • 7 Days
  • All India

Product Description



The PPC-3100S Fanless Panel PC is a powerful and reliable computing solution with a 256GB HDD and 4GB memory. It features an Intel processor, Windows/Linux OS, and a 17-inch display with a screen resolution of 391.4 x 312.5 x 55.35 mm. With a rugged aluminum front bezel and IP65/NEMA 4 protection, this panel PC is ideal for industrial applications. The Intel H110 chipset and LGA1151 socket support 7th/6th gen Intel Core i7/i5/i3, Celeron, and Pentium processors, providing versatile performance. The PC also includes features like audio input/output, multiple COM ports, Ethernet connectivity, and a 5-wire resistive touchscreen.

Audio 1 x Audio (Mic-in & Line-out)
BIOS AMI
Chipset Intel H110
COM 3 x RS-232 1 x RS-232/422/485
CPU LGA1151 socket 7th/6th gen Intel Core i7/i5/i3, Celeron & Pentium processor
Dimensions (W x D x H) 411.82 x 90 x 353.24 mm (16.21" x 3.54" x 13.91")
Ethernet 2 x 10/100/1000 Mbps (Intel i219-LM/i211-AT)
Front Bezel Aluminum w/ IP65/NEMA 4 rugged Protection
LCD Panel SXGA TFT LCD 250 nits 1280 x 1024 pixels
System Memory 2 x 288-pin Long-DIMM DDR4-2133, up to 32GB
Touchscreen 5-wire Resistive Type
Watchdog Timer 255 Levels, 1 to 255 sec.
Weight (net/gross) 6.4 kg (14.11 lb)/10.2 kg (22.49 lb)
Model Name/Number P1177E-500
Power Supply 240 VAC, 200W
Expansion 1 x PCIe x4 or 1 x PCI
Size 17inch Display
Brand Axiomtek
Processor i3


FAQs of PPC-3100S Fanless Panel PC:


Q: What is the warranty period for the PPC-3100S Fanless Panel PC?

A: The warranty period for the PPC-3100S Fanless Panel PC is specified as YES.

Q: What is the CPU type of the PPC-3100S Fanless Panel PC?

A: The CPU type of the PPC-3100S Fanless Panel PC is Intel.

Q: What is the size of the display on the PPC-3100S Fanless Panel PC?

A: The PPC-3100S Fanless Panel PC features a 17-inch display.

Q: Does the PPC-3100S Fanless Panel PC have an optical disk drive (ODD)?

A: Yes, the PPC-3100S Fanless Panel PC comes with an ODD.

Q: What type of touchscreen technology is used in the PPC-3100S Fanless Panel PC?

A: The PPC-3100S Fanless Panel PC utilizes a 5-wire resistive touchscreen.
